PmodOLED2 Reference Manual
www.digilentinc.com page 3 of 3
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
Connector J2
Pin
Signal Description
1 VCI/VD
DIO V
CI
and V
DDIO
Voltage Control
2 RES Power Reset
3 None Unused Pin
4 VCC V
BAT
Battery Voltage Control
7 D/C Data/Command Control
8 E/RD Read Data Enable
9 R/W Write Date Enable
10 VDDC V
DD
Logic Voltage Control
5, 11 GND Power Supply Ground
6, 12 VCC Power Supply
