it to “0”. See the Atmel Atmega168 data
sheet for more information.
On-Board User I/O
The Nanocon provides four on-board LEDs
for user output. The LEDs are connected to
I/O Port D, bits 4-7 (PD4-PD7). An LED is
turned on by writing the pin to logic 1 and
turned off by writing the pin to logic 0.
