IC2, ATmega165P Port Connections
MCU Port
Bit
Signal
Connector
Pin
Notes
RA00
U2-PA0
N/A
DIP Switch 1, DGIO port 0, chan 3
RA01
U2-PA1
N/A
DIP Switch 2, DGIO port 0, chan 3
RA02
U2-PA2
N/A
DIP Switch 3, DGIO port 0, chan 3
RA03
U2-PA3
N/A
DIP Switch 4, DGIO port 0, chan 3
RA04
U2-PA4
N/A
Push button BTN0, DGIO port 0, chan 2
RA05
U2-PA5
N/A
Push button BTN1, DGIO port 0, chan 2
RA06
U2-PA6
N/A
Push button BTN2, DGIO port 0, chan 2
RA07
U2-PA7
N/A
Push button BTN3, DGIO port 0, chan 2
RB00
U2-SS/PB0
N/A
Switch SW0, DGIO port 0, chan 1
RB01
U2-SCK/PB1
N/A
Switch SW1, DGIO port 0, chan 1
RB02
U2-MOSI/PB2
N/A
Switch SW2, DGIO port 0, chan 1
RB03
U2-MISO/PB3
N/A
Switch SW3, DGIO port 0, chan 1
RB04
U2-OC0A/PCIN12/PB4
JE-07
Also SPKR, Speaker/Buzzer output, DGIO Port 2, DPIO port 7
RB05
U2-OC1A/PCINT13/PB5
JE-08
DPIO port 7
RB06
U2-OC1B/PCINT14/PB6
JE-09
DPIO port 7
RB07
U2-OC2A/PCINT15/PB7
JE-10
DPIO port 7
RC00
U2-PC0
N/A
LED LD8, DGIO Port 0, chan 0
RC01
U2-PC1
N/A
LED LD9, DGIO Port 0, chan 0
RC02
U2-PC2
N/A
LED LD10, DGIO Port 0, chan 0
RC03
U2-PC3
N/A
LED LD11, DGIO Port 0, chan 0
RC04
U2-PC4
N/A
LED LD12, DGIO Port 0, chan 0
RC05
U2-PC5
N/A
LED LD13, DGIO Port 0, chan 0
RC06
U2-PC6
N/A
LED LD14, DGIO Port 0, chan 0
RC07
U2-PC7
N/A
LED LD15, DGIO Port 0, chan 0
RD00
U2-ICP1/PD0
N/A
LED LD0, DGIO Port 0, chan 0
RD01
U2-INT0/PD1
N/A
LED LD1, DGIO Port 0, chan 0
RD02
U2-PD2
N/A
LED LD2, DGIO Port 0, chan 0
RD03
U2-PD3
N/A
LED LD3, DGIO Port 0, chan 0
RD04
U2-PD4
N/A
LED LD4, DGIO Port 0, chan 0
RD05
U2-PD5
N/A
LED LD5, DGIO Port 0, chan 0
RD06
U2-PD6
N/A
LED LD6, DGIO Port 0, chan 0
RD07
U2-PD7
N/A
LED LD7, DGIO Port 0, chan 0
RE00
U2-RXD/PCINT0/PE0
N/A
Encoder ENC1, DGIO Port 1, chan 1
RE01
U2-TXD/PCINT1/PE1
N/A
Encoder ENC1, DGIO Port 1, chan 1
RE02
U2-XCK/AIN0/PCINT2/PE2
N/A
Encoder ENC2, DGIO Port 1, chan 2
RE03
U2-AIN1/PCINT3/PE3
N/A
Encoder ENC2, DGIO Port 1, chan 2
RE04
BTWI-SCL
J11-01
Private I2C bus SCL
RE05
BTWI-SDA
J11-02
Private I2C bus SDA
RE06
U2-DO/PCINT6/PE6
N/A
Enocder ENC1 button, DGIO Port 1, chan 0
RE07
U2-CLKO/PCINT7/PE7
N/A
Encoder ENC2 button, DGIO Port 1, chan 0
RF00
U2-ADC0/PF0
S1
DEMC port 3, DAIO port 1, DPIO port 6
RF01
U2-ADC1/PF1
S2
DEMC port 3, DAIO port 1, DPIO port 6
RF02
U2-ADC2/PF2
S3
DEMC port 3, DAIO port 1, DPIO port 6
