34
JB-03
10
RF02
U1RX/SDI1/RF2
35
JB-04
11
RF06
U1RTS/BCLK1/SCK1/INT0/RF6
36
J2-3,J2-4
40
RG03
SDA1/RG3
37
J2-1,J2-2
41
RG02
SCL1/RG2
38
N/A
N/A
VDD
39
N/A
N/A
RC12
OSC1/CLKI/RC12
X1, system clock
oscillator
40
N/A
N/A
RC15
OSC2/CLKO/RC15
X1, system clock
oscillator
41
N/A
N/A
VSS
42
JE-07
36
RD08
IC1/RTCC/INT1/RD8
43
JB-01
8
RD09
IC2/U1CTS/INT2/RD9
44
JD-03
26
RD10
IC3/PMCS2/PMA15/INT3/RD10
45
JD-09
30
RD11
IC4/PMCS1/PMA14/INT4/RD11
46
JC-09
22
RD00
OC1/RD0
PIN_OC1
47
N/A
N/A
RC13
SOSCI/CN1/RC13
X2, secondary oscillator
48
N/A
N/A
RC14
SOSCO/T1CK/CN0/RC14
X2, secondary oscillator
49
JC-10
23
RD01
OC2/RD1
PIN_OC2
50
JD-02
25
RD02
OC3/RD2
PIN_OC3
51
JD-08
29
RD03
OC4/RD3
PIN_OC4
52
JB-09
14
RD04
PMWR/OC5/IC5/CN13/RD4
PIN_OC5
53
JB-08
13
RD05
PMRD/CN14/RD5
54
JB-07
12
RD06
CN15/RD6
55
JB-10
15
RD07
CN16/RD7
56
N/A
N/A
VCAP/VDDcore
57
N/A
N/A
ENVREG
58
N/A
42
RF00
RF0
PIN_LED1, (LD4)
59
N/A
43
RF01
RF1
PIN_LED2, (LD5)
60
JA-01
0
RE00
PMD0/RE0
61
JA-02
1
RE01
PMD1/RE1
62
JA-03
2
RE02
PMD2/RE2
63
JA-04
3
RE03
PMD3/RE3
64
JA-07
4
RE04
PMD4/RE4
