D.A.S. Audio Variant Series Systems Guide User Manual

Page 12

System installation using the wall support AXW-V25

M8X30 DIN965

Rubber washer

M8x35 DIN 912

Grower washer

Metal washer

In order to hang the rest of the boxes the

captive rigging hardware and safety pins will be
used, and the procedures described on the 4.3
paragraph of this manual will be followed. The
picture below shows three

units fixed to

the wall.

variant25A

Three different washers must be used along

the M8x35 DIN912 screws and placed in the
following

order-

grower

(lock)

washer,

metal

washer and rubber washer.

Warning!! If three

units have to be

hung it is advisable to fix the box in the middle to
the wall mount accessory.

variant 25A

Then hang the first

unit from the

wall mount accessory. The two M8x30 DIN965
screws have to be removed from each side of the
box and replaced by two M8x35 DIN912 screws.

variant 25A

Up to three

units can be wall

mounted by means of the

accessory.

First the accessory must be fixed to the wall,

making sure in advance that the work load of the
wall allows for it. The wall mount accessory will be
attached to the wall using six nº 10 rawlplugs and
six 7 x 40 mm screws.

variant 25A

AXW-V25
