64
Environmental Condition Specifications
Environmental
Condition
Specifications The following table illustrates environmental condition specifications for the
DeviceMaster ATS-XPE.
Hardware
Specifications This table lists hardware specifications for the ATS-XPE.
Environmental Condition Value
Air temperature:*
System on (operational)
System off (storage)
0 to 60
o
C
-20 to 85
o
C
Altitude 0 to 10,000 feet
Heat output 47 BTU/Hr
Humidity (non-condensing):
System on (operational)
System off (storage) 8% to 80%
20% to 80%
* If the DeviceMaster ATS-XPE is stacked, the environment
air flow must insure that the Ambient Operating
Temperature does NOT exceed these limits.
Specification Description
Baud rates (default):
COM1 - AUX A
COM2 - CONSOLE
COM3 - PCMCIA modem
(optional)*
COM4 to COM11 - SERIAL PORTS
1-8 (optional)
57.6 Kbps
28.8 Kbps
57.6 Kbps
300 bps to 230.4 Kbps
Optional PC104 driver control
Data bits: 7 or 8
Parity: Odd, even, none
Stop bits: 1 or 2
Power input:
Frequency
Voltage 50/60 Hz
5 VDC
Power consumption 13.75 W
Current consumption 2.75 A
Dimensions 11” x 5.69” x 2.75” (W x L x H)
Weight:
Fully-configured system with
RocketPort PC104 and
PCMCIA options installed
Power supply
Octacable
3.52 lbs
0.62 lbs
1.12 lbs
* See Certified PCMCIA Adapters on Page 43 for the list of Comtrol
approved adapters.
