Setup
The UBC 120XLT comes with a rechargeable Nickel-Cadmium
Battery Pack. When fully charged, this Battery Pack will
supply up to 12 hours of dependable use. (With the Squelch
control in “closed” position.)
Before using the UBC 120XLT for the first time, or whenever
the LOW BATTERY Indicator appears on the LCD display, I
you should fully charge the Battery Pack.
Note: When the Battery Pack is low, the Low Battery
Indicator will start to blink. Afterabout tOminutes, the
scanner will shut itself off to prevent the battery from
becoming completely discharged.
Before charging, you must first install the Battery Pack
according to the steps below.
Charging the Battery Pack
1
.
Plug the AC Adaptor/Charger {AAD-2500U} into the
Charging Jack located on the Left side of the
UBC 120XLT . (You can use the scanner while it is
charging,)
WARNING! Use only an AACh2500U AC Adaptor/
Charger, (or one of the optional Cigarette
Lighter Power Cords listed on page 26). Any
other AC Adaptor or external cord or power plug
having over-voltage or reversed polarity can
cause overheating or damage to f/te circuitry.
2. Plug the AC Adaptor/Charger into a standard AC outlet.
To fully charge the battery, leave the Adaptor/Charger
connected for 14 to 16 hours.
3. When charging is complete, disconnect the Adaptor/
Charger from the AC outlet and from the Battery Pack.
Note: Dtscorjnecf the AC AdaptorX/harger from the unit
during a power failure.
Mounting the Flexible Antenna
Place the end of the antenna onto the BNC connector on top
of the scanner and turn clockwise until tight.
