www.vishay.com
2
Document Number 82177
Rev. 3, 23-Jun-03
VISHAY
TSOP62..
Vishay Semiconductors
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Electrical and Optical Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter Test condition Symbol Value Unit
Supply Voltage Pin 3 V
S
- 0.3 to 6.0 V
Supply Current Pin 3 I
S
5 mA
Output Voltage Pin 4 V
O
- 0.3 to 6.0 V
Output Current Pin 4 I
O
15 mA
Junction Temperature T
j
100 °C
Storage Temperature Range T
stg
- 40 to + 100 °C
Operating Temperature Range T
amb
- 25 to + 85 °C
Power Consumption T
amb
≤ 85 °C P
tot
50 mW
Parameter Test condition Symbol Min Typ. Max Unit
Supply Current V
S
= 5 V, E
v
= 0 I
SD
0.8 1.1 1.5 mA
V
S
= 5 V,
E
v
= 40 klx, sunlight
I
SH
1.4 mA
Supply Voltage V
S
4.5 5.5 V
Transmission Distance E
v
= 0, test signal see fig.1,
IR diode TSAL6200,
I
F
= 400 mA
d 35 m
Output Voltage Low (Pin 4) I
OSL
= 0.5 mA,
E
e
= 0.7 mW/m 2 ,
test signal see fig. 1
V
OSL
250 mV
Irradiance (30-40 kHz) Pulse width tolerance:
t
pi
- 5/f
o
< t
po
< t
pi
+ 6/f
o
,
test signal see fig.1
E
e min
0.35 0.5 mW/m 2
Irradiance (56 kHz) Pulse width tolerance:
t
pi
- 5/f
o
< t
po
< t
pi
+ 6/f
o
,
test signal see fig.1
E
e min
0.4 0.6
mW/m 2
Irradiance t
pi
- 5/f
o
< t
po
< t
pi
+ 6/f
o
,
test signal see fig. 1
E
e max
30
W/m
2
Directivity Angle of half transmission
distance ϕ
1/2
± 50 deg
