Document #: 38-05353 Rev. *D Page 16 of 27
209-ball BGA Boundary Scan Order [13, 14]
CY7C14604V33 (512K x 72)
Bit# Ball ID Bit# ball ID Bit# ball ID Bit# ball ID
1 W6 36 6F 71 6H 106 3K
2 V6 37 8K 72 6C 107 4K
3 U6 38 9K 73 6B 108 6K
4 W7 39 10K 74 6A 109 2K
5 V7 40 11J 75 5A 110 2L
6 U7 41 10J 76 5B 111 1L
7 T7 42 11H 77 5C 112 2 Mbit
8 V8 43 10H 78 5D 113 1 Mbit
9 U8 44 11G 79 4D 114 2N
10 T8 45 10G 80 4C 115 1N
11 V9 46 11F 81 4A 116 2P
12 U9 47 10F 82 4B 117 1P
13 P6 48 10E 83 3C 118 2R
14 W11 49 11E 84 3B 119 1R
15 W10 50 11D 85 3A 120 2T
16 V11 51 10D 86 2A 121 1T
17 V10 52 11C 87 1A 122 2U
18 U11 53 10C 88 2B 123 1U
19 U10 54 11B 89 1B 124 2V
20 T11 55 10B 90 2C 125 1V
21 T10 56 11A 91 1C 126 2W
22 R11 57 10A 92 2D 127 1W
23 R10 58 9C 93 1D 128 6T
24 P11 59 9B 94 1E 129 3U
25 P10 60 9A 95 2E 130 3V
26 N11 61 8D 96 2F 131 4T
27 N10 62 8C 97 1F 132 5T
28 M11 63 8B 98 1G 133 4U
29 M10 64 8A 99 2G 134 4V
30 L11 65 7D 100 2H 135 5W
31 L10 66 7C 101 1H 136 5V
32 K11 67 7B 102 2J 137 5U
33 M6 68 7A 103 1J 138 Internal
34 L6 69 6D 104 1K
35 J6 70 6G 105 6N
Note:
14. Bit# 138 is preset HIGH.
