Setting Oven Controls
Setting Broil - Upper Oven Only
The
L!ZU
pad controls the Broil feature. When broiling, heat radiates downward from the oven broiler for even coverage. The
Broil temperature may be set between 400°F and 550°F.
The broil pan and broil pan insert used together allow dripping grease to drain and be kept away from the high heat of the
oven broiler. DO NOT use the broil pan without the insert (See Fig. 4). DO NOT cover the broil pan insert with foil. The
exposed grease could catch fire.
f » MjjJiiyikO Should an oven fire occur, leave the oven door closed and turn off the oven. If the fire continues, throw baking
soda on the fire or use a fire extinguisher. DO NOT put water or flour on the fire. Flour may be explosive and water can cause
a grease fire to spread and cause personal injury.
____________________ INSTRUCTIONS___________________________ PRESS DISPLAY
To set the oven to broil at 550°F
1. Place the broiler pan insert on the broiler pan. Then place the
food on the broiler pan insert. DO NOT use the broiler pan
without the insert. DO NOT cover the broiler insert with foil. The
exposed grease could ignite.
2. Arrange the interior oven rack and place the broiler pan on the
rack. Be sure to center the broiler pan directly under the broiler
element. Make sure the oven door is closed. Preheat the oven for
3.
4.
5.
6 .
7.
5 minutes.
Press o T;.
Press S (Fig. 1).
If a lower broil temperature is desired (minimum broil
temperature setting is 400°F), press the desired temperature
before continuing to step 6 .
Press '—' (Fig. 2). The oven will begin to broil.
Broil on one side until food is browned; turn and cook on the
second side. Season and serve. Note: Always pull the rack out to
the stop position before turning or removing food.
8. To cancel broiling or if finished broiling press's—' (Fig. 3).
Upper
Oven
B
550'
1-
I- J U
Fig
.
1
5S0'
h
I-
D n
J U
Fig.
2
1- □n
Fig. 3
Broiling Times and Searing Grill (if equipped)
Use the following table for approximate broiling times. Increase or decrease broiling times,
or move the broiling pan to a different rack position to suit for doneness. If the food you
are broiling is not listed in the table, follow the instructions provided in your cookbook and
watch the item closely. Use the Searing Grill for meats and steaks if desired. Before placing
the meat, be sure to heat the Searing Grill using Broil for 10 minutes. Cook times should be
reduced 1-2 minutes per side when cooking with the Searing Grill. Place Searing Grill on top
of Broiler Pan and insert for meats and steaks (See Fig. 5).
Food
Item
Rack
Position
Temp
Setting
Cook Ti
1st side
me
2nd side Doneness
Steak 1” thick 7 550° F 6:00 4:00 Rare
7 550° F 7:00 5:00 Medium
Pork Chops 3/4” thick 7 550° F 8:00 6:00 Well
Chicken - Bone In 8 450° F 20:00 10:00 Well
Chicken - Boneless 7 450° F 8:00 6:00 Well
Fish 7 500° F 13:00 n/a Well
Shrimp 8 550° F 5:00 n/a Well
Hamburger 1” thick 7 550° F 9:00 7:00 Medium
8 550° F 10:00 8:00 Well
Supplied with some
models - Fig. 4
Searing
Supplied with some
models - Fig. 5
22
