6.
Place paper towel under elbow. Turn on
water supply and check for leaks.
Drain Connection
7
.
Route drain hose to avoid contact with
motor, door springs, water line, cabinet
or flooring. Insert a cloth, putty or
caulking compound in hole around drain
hose where hose passes through
cabinet to help minimize vibration noise.
Place a shallow pan O (pie or cake
pan) under drain connector ©. Remove
drain hose connector cap ©. Put the
drain hose clamp @ onto the
connector.
9.
Push drain hose O onto connector ©
up to the stops © on connector.
Use pliers to open clamp © and
slide clamp over drain hose O and
connector ©. Release clamp and check
that the drain hose is held securely on
connector.
