continued from page 10
10
.
Drain hose
Cut a 1-1/2" (3.8cm) diameter hole in
cabinet wali or floor on the side of the
opening ciosest to the sink.
11
.
11a.
i
1
HU
.L
l
Connect drain hose to waste tee or
waste disposer following one method.
If you have:
and:
no to step:
a waste disposer
an air gap
11a.
no air gap*
11c.
no waste disposer
an air gap
11b.
no air gap*
11d.
*an air gap is recommended
Waste disposer + air gap
1. Remove the disposer knockout plug.
Cut end of drain hose O if needed
(do not cut ribbed section).
2. Attach drain hose to air gap O with
spring-type clamp O.
3. Use a rubber hose connector* O
with spring or screw-type clamps*
© to connect air gap to disposer
inlet O.
This connection © MUST be before
drain trap © and at least 20” (50.8cm)
above the floor where dishwasher will
be installed. Goto step 12.
No waste disposer + air gap
1. Cut end of drain hose O if needed
(do not cut ribbed section).
2. Attach drain hose to air gap © with
1-1/2"-2" (3.8-5cm) screw clamp.
3. Use a rubber hose connector* O
with spring or screw-type clamps*
© to connect air gap to waste tee Q.
This connection O MUST be before
drain trap ® and at least 20” (50.8cm)
above the floor where dishwasher will
be installed. Goto step 12.
