continued from page 18
Water Connection
HBPRJL TIP:
Compiesshm Atthigs:
. Slide nut Oonta copper tubmg
O about 1 inch (2.5cnt).
, Slide femde # onto the hibing>
Do not position ferrule on the
end of the tutdng.
. Rft tile tubing into the ^bow 0
as far as it wUt go>
. SOde the nut and ferrule forward
and start the not onto the ^bow
threads 0. Be careful when
handling and positioning the
copper tutdng. It bends and
kiriks easily.
HEtPFUL TIP:
Hold water vidve mounting
bracket with pliers white
attaching copper tubing.
To prevent vibration during operation,
route the water supply line so that it
does not touch the dishwasher base,
frame or motor
With copper tubmg O pushed into
compression fitting as far as it will go,
use an adjustable wrench and tighten
compression fitting nut
O
to elbow ©
on water inlet valve
19
