B-1
Cisco 1751 Router Hardware Installation Guide
78-11258-04
A P P E N D I X
B
Cabling Specifications
This appendix describes cables and cabling guidelines for the router and contains
the following sections:
• Ethernet Cables
• Ethernet Network Cabling Guidelines
• Console Cable and Adapters
• VIC Cables and Pinouts
• Cables and Pinouts for 2-Port ISDN BRI Card
Note For detailed information about cables used with Cisco WICs and VICs, refer to
the Cisco WAN Interface Cards Hardware Installation Guide that comes with
each of the cards.
Ethernet Cables
This section describes the Ethernet cables you use to connect the router to your
local Ethernet network. A 10/100BaseTX router, like the Cisco 1751 router,
requires Category 5 unshielded twisted-pair (UTP) or shielded twisted-pair (STP)
cable.
Table B-1 describes the pinouts for a RJ-45-to-RJ-45 Ethernet cable.
