Cisco 1751 Router Hardware Installation Guide

78-11258-04

Chapter 1

Cisco 1751 Router Overview

Rear-Panel Ports and LEDs

Use the rear-panel LEDs (see

Table 1-3

) during router installation to confirm that

you have correctly connected all cables to the router.

Table 1-2

Rear-Panel Connectors

Connector/Slot

Label/Color

Description

Ethernet port

10/100-Mbps
ETHERNET
(yellow)

Router connection to the local Ethernet network. This
port autosenses the speed (10 or 100 Mbps) and duplex
mode (full or half) of the device to which it is connected
and then operates at the same speed and in the same
duplex mode.

Auxiliary port

AUX
(black)

Modem connection for remote configuration using
Cisco IOS software.

Console port

CONSOLE
(light blue)

Terminal or PC connection for local configuration using
Cisco IOS software.

WIC/VIC slot

SLOT 0

Supports either a Cisco WIC or VIC. For detailed
information, refer to the Cisco WAN Interface Cards
Hardware Installation Guide
that comes with every
card.

WIC/VIC slot

SLOT 1

Supports either a Cisco WIC or VIC. For detailed
information, refer to the Cisco WAN Interface Cards
Hardware Installation Guide
that comes with every
card.

VIC slot

SLOT 2

Supports one Cisco VIC. For detailed information, refer
to the Cisco WAN Interface Cards Hardware
Installation Guide
that comes with every card.

Power socket

+5, +12, –12
VDC

Router connection to the external power supply.

Protective earth

Ground wire

Router connection to earth ground by using a green and
yellow 14 AWG ground wire.
