Page 9
8
2.1 Package Contents
The dome carton contains the following:
Description
Qty
High Speed Dome mechanism
1
Camera Module (Sony 18x or LG27x)
1
Clear Acrylic dome cover
1
Camera shroud (black)
1
Bag of Screws (4xM2*4, 4xM3*5)
1
8 conductor Control/Power/Video harness
1
24VAC transformer (optional)
1
Wall bracket (optional)
1
Instruction manual
1
Camera Ribbon cable (spare)
1
Figure 1. Illustrates the upper layer of the packing material (top half)
Figure 2. Illustrates the lower layer of the carton (bottom half).
Fig.1
Fig. 2
Acrylic
Dome Cover
Manual, Quality certificate,
Spare camera ribbon cable
Cable Harness and connectors
24 VAC, 2 Amp
Transformer
Wall Bracket
Shroud Screws
Camera Shroud
High Speed Dome & Camera
