Costar CDC2500MI User Manual
Page 24
23
6.
Name Display ON/OFF < 2. Sector Setup << Sector setup Press OPEN or Joy stick Left or Right to enter 1. Number ( 1 ~ 9 ) << Number selection 2. Name _ _ _ _ _ _ _ _ << Name editing Pan Start POS 0.0 4. Pan End POS 0.0 5. Tilt Start POS 0.0 6. Tilt End POS 0.0 7. Name Display ON/OFF < Joystick Left or Right to select 3. Coordinates ON/OFF < On/Off Joystick Left or Right to select 4. Crosshairs ON/OFF < On/Off Joystick Left or Right to select 5. Start-UP Scr Msg ON/OFF < Joystick Left or Right to select _ _ _ _ _ _ _ _ IRIS CLOSE When Done IRIS CLOSE When Done IRIS CLOSE When Done IRIS CLOSE When Done << Joystick Left or Right when programming to select preshot and press OPEN to confirm. Joy stick left or right to select (0~9 or A~Z). OPEN to confirm selection. Press CLOSE to exit or return to the previous menu level when programming is done. Joystick Left or Right to select Joy stick Left or Right to select Press OPEN or Joy stick Left or Right to enter < Press OPEN or Joystick Left or Right to enter Capture the start point and press CLOSE to exit and return to previous menu. << Setup pan end point. Press OPEN or Joystick Left or Right to enter Capture the end point and press CLOSE to exit and return to previous menu. << Setup tilt start point. Press OPEN or Joystick Left or Right to enter Capture the start point and press CLOSE to exit and return to previous menu. << Setup tilt end point. Press OPEN or Joystick Left or Right to enter Capture the end point and press CLOSE to exit and return to previous menu. IRIS CLOSE to Exit IRIS CLOSE to Exit IRIS CLOSE to Exit
3.
0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N
O P Q R S T U V W X Y Z _
IRIS CLOSE When Done
Press
