18

3.3 Communication Settings

Before installation and use, the unique address for each dome and the communication protocol including
transmission speed (baud rate) should be set to correspond with the chosen control system.

3.4

Setting the Protocol and baud rate settings for each dome device.











CAUTION:
The protocol and baud rate of dome device
should match the settings of the controller. In order to take
effect the dome must be power cycled after each change.










3.5

Address setting of each dome

. To prevent damage, each dome must have a unique address (ID).









Dome device range: 0~255.


On/Off

Baud rate

5

th

digit

6

th

digit

2400

OFF

OFF

4800

OFF

ON

9600

ON

OFF

19200

ON

ON

On/Off

status

Protocol type

1

st

digit

2

nd

digit

3

rd

digit

4

th

digit

5

th

digit

6

th

digit

PELCO-D

ON

ON

OFF

OFF

**

**

PELCO-P

OFF

OFF

ON

OFF

**

**

Auto Detect

OFF

OFF

OFF

OFF

**

**

System reserve

ON

ON

ON

ON

**

**

✌✍

✑✒

✓✔

✑✒

✓✔

✑✒

✓✔

✑✒

✓✔

This example illustrates PELCO-D

protocol and Baud rate of 2400.

Setting address for dome device
(this figure shows the address of
dome device No 1).

O

n/O

ff s

w

itc

h

Setting method: The sum of switch numbers in the ON

position is the address of the dome device. (Binary Method)









Calculation example
of dome device address:



1
2
4
8

16

32

64

128

2

4

16

2+4+16=22

the dome address is:

22

O

n/o

ff

sw

itc

h

an

d

m

atc

hin

g n

um

be

rs

O

n/O

ff D

ip

sw

itc

h

B

au

d r

ate

se

ttin

g

Pr

oto

co

l s

ett

in

g
