9
English
Start-up
5. Slide off the battery cover on the magnifying
glass. Insert the four AA cells into the body
(see battery orientation indicated on the
cover).
6. The magnifier assembly is supplied
separately. Slide the magnifier clamp plate
onto the body of the magnifier and tighten.
Slide the circular shaft through the clamp
plate and tighten the clamping knob. Slide
the assembly onto the instrument and adjust
its position for optimum viewing of the
sample.
7. Turn the two handles on the top clamping
ring anti-clockwise to release the zero plate
[1] from the clamp ring [2] - see below.
Rotate the operating handles [3] four turns
anticlockwise (as viewed from the right
hand side of the instrument) to lower the
hemispherical indenter.
8. The Cupping Tester is now ready for use.
