INSTALLATION, OPERATION & MAINTENANCE

1-5

1.5 - TECHNICAL DATA

(THE NAME PLATE IS PLACED UNDER THE FRONT JACKET NEXT TO THE

CONTROL PANEL.)

Model Number

Min Input

Max Input

Max Output*

Net IBR Rating

MLX-303

45,500 303,000 260,000-279,000 237,000

MLX-454

45,500 454,000 390,000-418,000 355,000

MLX-606

45,500 606,000 521,000-558,000 474,000

MLX-757

45,500 757,000 651,000-696,000 592,000

MLX-909

45,500 909,000 781,000-835,000 710,000

MLX-1060

45,500 1,060,000 912,000-975,000

829,000

DIMENSIONS:

Model Number

Height

Width

Depth

Dry Weight

MLX-303

42” (1067 mm)

28” (711 mm)

27” (686 mm)

405 lbs. (183.7 kg)

MLX-454

42” (1067 mm)

28” (711 mm

27” (686 mm)

484 lbs. (219.6 kg)

MLX-606

42” (1067 mm)

33” (838 mm)

27” (686 mm)

575 lbs. (260.8 kg)

MLX-757

42” (1067 mm)

38” (965 mm)

27” (686 mm)

673 lbs. (305.2 kg)

MLX-909

42” (1067 mm)

44” (112 mm)

27” (686 mm)

765 lbs. (346.8 kg)

MLX-1060

42” (1067 mm)

49” (1245 mm)

27” (686 mm)

869 lbs. (394.0 kg)

SPECIFICATIONS:

Model

Number

MLX-303 MLX-454 MLX-606 MLX-757 MLX-909 MLX-1060

Boiler
