PR2: 08/02/12 Page 6 of 20 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 • Phone: 800-526-0288
Installing Belimo Motorized Valves on AERCO Benchmark Boilers
Technical instruction Document
TID-0028_0C
Wiring Diagram Selection Guide for AERCO Boiler Valve Controller and AERCO supplied
Belimo Valves
How to use the below chart:
1. From the first column, identify the AERCO Boiler Series to which the Belimo valve will be
applied. If the Belimo valve is being installed on a BMK boiler that is already in the field, to
determine if the boiler is equipped with BMK Pump Relay Option 69102, see Figure 1 on
next page.
2. From the second column, identify the AERCO part number of the Belimo valve being used.
3. From the third column, identify which AERCO Boiler Valve Controller is being used in the
application.
4. Use the resulting wiring diagram from the last column.
Boiler Series Motorized Valve
AERCO Boiler Valve
Controller (BVC)
Wiring
Diagram to
Use
Benchmark Boilers equipped
with BMK Pump Relay Option
69102
Belimo 24-240VAC/24-
125VDC, Spring Return
Open Valves. AERCO Part
Numbers
92084-1
92084-2 (Dual Actuator)
None SD-A-904
24V, Power open/power
close Valves. Part Numbers
92084-3
92084-4
92084-5
92084-6
92084-7
None SD-A-863
Benchmark Boilers NOT
equipped with BMK Pump
Relay Option 69102;
KC1000 Boilers
Belimo 24-240VAC/24-
125VDC, Spring Return
Open Valves. AERCO Part
Numbers
92084-1
92084-2 (Dual Actuator)
None SD-A-905
120V 4-Boiler BVC
P/N 64095
SD-A-906
120V 12-Boiler BVC
P/N 64096
SD-A-907
24V 4-Boiler BVC
P/N 64097
SD-A-909
24V 12-Boiler BVC
P/N 64098
SD-A-911
24V, Power open/power
close Valves. Part Numbers
92084-3
92084-4
92084-5
92084-6
92084-7
None SD-A-864
24V 4-Boiler BVC
P/N 64097
SD-A-908
24V 12-Boiler BVC
P/N 64098
SD-A-910
