Configuration
26
Kofax Reporting Administrator's Guide
b In the Transport field, select how sender and receiver WSA instances should
communicate. The available options are HTTP, MSMQ, and IBM WebSphere MQ. The
setting on the sender and receiver must match.
c In the Central URL field, specify the URL of the receiver WSA in the central site. If
WSA receiver is installed in a network load balancing mode, specify the NLB port.
This field is only available for sender WSA (application site).
When you are using WSA Receivers running in a network load balancing
configuration, use the NLB IP address and port.
Note Do not enter the URL of the sender WSA into this field. Messages will be sent in
a loop.
d In the Central Queue field, specify the queue to use. This field is only available if you
did not use HTTP as the transport option. E.g.:
▪ IBM MQSeries:
"REPORTING.CLIENT.QUEUE.MANAGER:REPORTING.REMOTE.QUEUE"
▪ MSMQ: "DIRECT=TCP:10.20.30.40\MyQueue"
3 Go to the HTTP Settings tab.
a In the Local Port field, specify the port of the local web server. The default is 25480
for application sites and 25481 for central site. You might need to modify this value in
case of port conflicts.
b In the Local IP Address field, optionally specify the IP address of the local interface
used for web portal. The web portal offers monitoring functions, mostly for
troubleshooting.
c In the Local server name field:
▪ For WSA Receiver, this parameter is not used.
▪ For WSA Sender, specify the name of the local server, as it is known to the client
applications. E.g., if client computers know the server under a different name,
specify that name here.
d Select the SSL Active field to enable secure communication.
4 If you enabled SSL, fill in the configuration fields in the SSL Certificate tab.
5 Click Advanced to display advanced parameters. Configuring advanced parameters is
necessary e.g. in these cases:
▪ Message queue transport
▪ Troubleshooting, configuring traces
▪ Password protection of WSA
▪ Load balancing configuration of WSA Receiver
▪ WSA storage management
▪ Performance tuning
Refer to
Configuring WSA Advanced Settings
.
6 Click Save. Click Exit and restart service.
