Inovonics FA116 User Manual

Page 13

LIT-FA116-USER

01860

Programming FA426 Receivers

with the FA116 Executive Programmer (Continued)

Progammer requests System ID. nnn = 0 to 255 (decimal).

By default nn = 02 or displays the first available unprogrammed point,
but user may enter value from 01 to 16 (decimal). See note.

Asked only if nn = 01. If YES, next four options are skipped.

Is the external switch loop normally open or closed?
Arrow keys toggle between NORM/CLOSED and NORM/OPEN.

Is a 2.2K end of line resistor being used to monitor the transmitter (FA200 or
FA210)switch loop? Arrow keys toggle between YES and NO.

Is FA200W or FA210W widegap magnet contact being used? Arrow keys
toggle between YES and NO.

How often should supervisory data be transmitted?
Arrow keys toggle between 10, 30, or 60 seconds or 5 minutes.
NONE is shown when point nn = 01.

Press

ENTER to proceed with transmitter programming,

press

A to go through transmitter options again.

Connect transmitter and press transmitter reset to program device, or press
A to save point program and return to the point number selection screen.

Indicates successful transmitter programming sequence. Display remains for
about 3 seconds, then returns to the point number selection screen.

Note: Point 01 must always be either a command transmitter or an unsupervised device.

POINT nn: ENTER

TO PGM / ENTER PT

COMMAND TX?

Å YES Æ

ENTER TO PROGRAM

"A" to REVIEW

CONNECT TX+ RESET

OR PRESS "A"

POINT NUMBER nn

PROGRAMMED

CHECK-IN TIME

Å 60 SECONDS Æ

USE INTERNAL

CONTACT: Å YES Æ

END OF LINE

RESISTOR: Å YES Æ

EXT SWITCH TYPE

Å NORM/CLOSED Æ

Program

Points

SYSTEM ID: nnn
