OPERATION AND INSTALLATION MANUAL
Page 13
Installing Load
Point Assemblies
with Anchor Bolts
The outline drawing located on the
www.hardysolutions.com Web Site provide the Base
Plate and Top Plate dimensions for the Load Point
Assembly. They include the thru hole diameters and
center distances.
Installing the
Base Plate
Step 1.
Make sure that the concrete foundation is
level.
Step 2.
To assist in the installation of the anchor
bolts we recommend creating a template
using the thru hole diameters of the top
plate mounting dimensions. For drilling
dimensions, see the drawings accessed
from the Products page on the Hardy
Process Solutions web site. Note that the
holes for top and bottom are in direct
alignment, but the thickness of the top and
bottom plates differ.
Fig. 16 and Table 1 provide side dimensions and hole
diameters only.
