Round Vessel with 3
Load Point
Assemblies
FIG. 6: THREE LOAD CELLS IN ROUND
CONFIGURATION
Round Vessel with 3
Load Point
Assemblies - Angle
Config. #1
FIG. 7: ANGLE FOR FIXED AND BUMPER
LOAD CELLS IN ROUND CONFIGURATION
F
S
B
120
o
120
o
120
o
F
S
B
<45
o
