HI 2151 SERIES WEIGHT CONTROLLERS REMOTE I/O OPTION
5-30
TABLE 5-30: BLOCK READ COMMAND NUMBER 70: READING RESPONSE CODE AFTER A BLOCK WRITE
Block Read or Block
Write Error Codes Decimal HEX Description
06 06 Acknowledge good data received
21 15 NACK - illegal command
22 16 Exceeded maximum legal words for block read and
write
23 17 In CAL mode
Block Write Error
Codes 49 31 Scale in motion (for example: unable to calibrate
while in motion)
50 32 Current weight sensed over scale capacity (only
functional for command 51)
51 33 Weight not within zero tolerance, unable to zero
52 34 Insufficient change in weight to calibrate span
(display error #18)
53 35 Decimal point places must be between 0 and 4
54 36 Not a valid graduation size
55 37 Motion value must be greater than graduation size
56 38 Zero tolerance value must be greater than
0 and positive.
57 39 Acceptable number of averages is between
1 and 200
58 3A Span weight value, during calibration, must be
positive
59 3B Scale capacity value must be positive
60 3C Midpoint linearity value must be positive
61 3D Rate-of-Change time units selection must be 0,1 or 2
62 3E Rate-of-Change time base out of range
63 3F BCD option not installed
64 40 Invalid BCD card bit request
65 41 Analog output not installed
66 42 Analog output request must be between 0 and 4
Error Codes for
Block Write 59 67 43 Invalid serial port (RS-232) format request
68 44 Serial configuration values 0 or 1
69 45 Baud rate request out of range
70 46 Parity request out of range, must be 0,1,or 2
BLOCK READ COMMAND NUMBER 70: Reading response code after a block write
WORD DEFINITIONS # WORDS
START
WORD
Write command number (not 70 but the command number of the write performed)
Bits 0 - 7 1 0
Response code from table below
Bits 8-15
TOTAL NUMBER OF WORDS 1
