Mount the Intercom

Operations Guide

930181B

CyberData Corporation

2. To fasten the Intercom:

•

For wall mounting, use the two 8-32 X 1/4" FLAT HEAD PHILLIPS MACHINE SCREW
and the one 10-24 X 5/16" PAN HEAD PHILLIPS MACHINE SCREW to secure the
Intercom.

Figure A-1. VoIP Intercom Assembly

4 x Mounting Screw

Face Plate

2 Gang Box

and

PCB Assembly
