User's Guide
Control 1 Vol OutL Parameter 1 master channel not applicable
Control 2 Vol OutR Parameter 2 master channel not applicable
Control 3 Direct Vol Ch. 3 Parameter 44 master channel not applicable
Control 4 Direct Vol Ch. 4 Parameter 45 master channel not applicable
Control 5 Direct Vol Ch. 5 Parameter 46 master channel not applicable
Control 6 Direct Vol Ch. 6 Parameter 47 master channel not applicable
Control 7 Direct Vol Ch. 7 Parameter 48 master channel not applicable
Control 8 Direct Vol Ch. 8 Parameter 49 master channel not applicable
Control 9 Direct Vol Ch. 9 Parameter 50 master channel not applicable
Control 10 Direct Vol Ch. 10 Parameter 51 master channel not applicable
Control 11 Vol Inp L Parameter 7 master channel not applicable
Control 12 Vol Inp R Parameter 8 master channel not applicable
Control 13 Vol Thru L Parameter 3 master channel not applicable
Control 14 Vol Thru R Parameter 4 master channel not applicable
Control 15 Undo History Parameter 21 master channel not applicable
Control 16 LoadList Nr. Parameter 13 master channel not applicable
The following two presets are examples for applications of the NRPN controllers in connection with the
inc/dec controllers. So far no device is able to recognize this message type. But from our point of view
this would include a lot of advantages. We think that the reason is that so far no lo-cost controllers like
Pocket Dial have been available and we hope that the manufacturers will take into consideration this
very flexible relative controlling idea.
Preset 105 AWE/SB 1&2 IncDec NRPN & Inc/Dec Channel Remark
Control 1 Filter Cutoff Coarse see appendix master channel not applicable
Control 2 Filter Resonance Coarse see appendix master channel not applicable
Control 3 Vibrato Rate Coarse see appendix master channel not applicable
Control 4 Vibrato Depth Coarse see appendix master channel not applicable
Control 5 Vibrato Delay Coarse see appendix master channel not applicable
Control 6 EG- Attack Coarse see appendix master channel not applicable
Control 7 EG Decay Coarse see appendix master channel not applicable
Control 8 EG Release Coarse see appendix master channel not applicable
Control 9 LFO 1 Delay see appendix master channel not applicable
Control 10 LFO 1 Freq see appendix master channel not applicable
Control 11 Env1 Delay see appendix master channel not applicable
Control 12 Env1 Hold see appendix master channel not applicable
Control 13 Env1 Sustain see appendix master channel not applicable
Control 14 Env2 Attack see appendix master channel not applicable
Control 15 Env2 Decay see appendix master channel not applicable
Control 16 Env2 Release see appendix master channel not applicable
Preset 106 GS/XG Drum Level NRPN& IncDec
see appendix master channel not
applicable
