User's Guide
Presets with the new abilities of Pocket Dial
14 bit controllers
Preset 81 MSB/LSB Ctrl 0-7 Controller 0-7/32-39 master channel feedback
Preset 82 MSB/LSB Ctrl 8-15 Controller 8-15/40-47 master channel feedback
Preset 83 MSB/LSB Ctrl 16-23 Controller 16-23/48-55 master channel feedback
Preset 84 MSB/LSB Ctrl 24-31 Controller 24-31/56-63 master channel feedback
These presets enable the 14 bit control using high and low byte of a controller. The difference of the
controller numbers for high and low byte is always 32, e.g. controller 8 and 40. If one of these presets is
selected the Pocket Dial checks if the two controllers of a 14 bit controller pair are assigned to two
knobs of Pocket Dial. If this applies a possible overrun or underrun of the least sigificant byte (LSB, i.e.
controller 40 in the example) is considered for the calculation of the most significant byte (MSB, i.e.
controller 8 in the example). For details please refer to appendix (transmission of absolute data).
Increment / Decrement messages
Preset 85 Reaktor IncDec Controllers 0 - 15 master channel not applicable
Preset 86 Reaktor IncDec Controllers 16 - 31 master channel not applicable
Preset 87 Reaktor IncDec Controllers 32 - 47 master channel not applicable
Preset 88 Reaktor IncDec Controllers 48 - 63 master channel not applicable
These are examples for relative controller messages (binary mode) suitable e.g. for Native Instruments
'Reaktor'. For details please refer to appendix (transmission of increment/decrement data).
Preset 89 IncDec controller Parameter 0 - 15 master channel not applicable
Preset 90 IncDec controller Parameter 16 - 31 master channel not applicable
Preset 91 IncDec controller Parameter 32 - 47 master channel not applicable
Preset 92 IncDec controller Parameter 48 - 63 master channel not applicable
Preset 93 IncDec controller Parameter 64 - 79 master channel not applicable
Preset 94 IncDec controller Parameter 80 - 95 master channel not applicable
Preset 95 IncDec controller Parameter 96 - 111 master channel not applicable
Preset 96 IncDec controller Parameter 112 - 127 master channel not applicable
The presets 89 ~ 96 make available all possible 128 Inc/Dec controller messages in increasing order (8
presets with 16 inc/dec controller messages each). The MIDI channel is the master channel. This
preset group was made especially for softsynths and virtual synths that enable the control of parameters
with the inc/dec controller messages. Some of these applications include a learning feature that enables
to tell the application which knob of Pocket Dial is used to control the desired parameter (e.g. the
CronoX software, see 'www.Linplug.com' in the appendix). For details please refer to appendix
(transmission of increment/decrement data).
The following 5 presets are adaptions for the programm 'CrusherX-Live' (see www.CrusherX.com in the
appendix):
Preset 97 Crusher-X Cloud Inc/Dec-Controller Channel Remark
Control 1 Vol OutL Parameter 1 master channel not applicable
Control 2 Direct Vol Ch. 3 Parameter 44 master channel not applicable
Control 3 Vol Thru L Parameter 3 master channel not applicable
Control 4 Vol InpL Parameter 7 master channel not applicable
Control 5 Vol DCO Parameter 9 master channel not applicable
Control 6 Vol Sampler Parameter 10 master channel not applicable
Control 7 Manual X Parameter 11 master channel not applicable
Control 8 Manual Y Parameter 12 master channel not applicable
Control 9 Generators Parameter 14 master channel not applicable
