✠ ✡ ☛ ☞ ✌ ✍ ✎ ✏ ✑ ✒ ✠ ✡ ☛ ☞ ✌ ✍ ✎ ✏ ✑ ✒ User's Guide Page 19
Preset 43 XG Mpart-Effect Controller Channel Remark
Control 1 High EQ Frequency SysEx - (no feedback)
Control 2 Low EQ Frequency SysEx - (no feedback)
Control 3 undefined
Control 4 Dry SysEx - (no feedback)
Control 5 undefined
Control 6 undefined
Control 7 undefined
Control 8 undefined
Control 9 Hi Eq Gain SysEx - (no feedback)
Control 10 Lo Eq Gain SysEx - (no feedback)
Control 11 undefined
Control 12 Reverb SysEx - (no feedback)
Control 13 Chorus SysEx - (no feedback)
Control 14 Variation SysEx - (no feedback)
Control 15 Pan SysEx - (no feedback)
Control 16 Level SysEx - (no feedback)
Preset 43 is similar to preset 16 and offers general effects control for an XG instrument.
Preset 44 XG AD & Wave Level SysEx master channel (no feedback)
Preset 45 XG AD & Wave Pan SysEx master channel (no feedback)
Preset 46 XG AD & Wave Reverb Send SysEx master channel (no feedback)
Preset 47 XG AD & Wave Chorus Send SysEx master channel (no feedback)
Preset 48 XG AD & Wave Variation Send SysEx master channel (no feedback)
Preset 49 XG AD & Wave Dry Level SysEx master channel (no feedback)
Presets 44 ~ 49 control the A/D inputs 1 and 2 as well as the 12 wave channels on relevant Yamaha
sound cards. These relevant controls are shown below. Note that knobs 15 and 16 have no defined
function for these presets.
Control 1 AD Input 1 Control 9 W7
Control 2 AD Input 2 Control 10 W8
Control 3 W1 Control 11 W9
Control 4 W2 Control 12 W10
Control 5 W3 Control 13 W11
Control 6 W4 Control 14 W12
Control 7 W5 Control 15 undefined
Control 8 W6 Control 16 undefined
Preset 50 XG Effects - EQ Controller Channel Remark
Control 1 EQ Gain 1 SysEx master channel (no feedback)
Control 2 EQ Frequency 1 SysEx master channel (no feedback)
Control 3 EQ Q1 SysEx master channel (no feedback)
Control 4 EQ Gain 2 SysEx master channel (no feedback)
Control 5 EQ Frequency 2 SysEx master channel (no feedback)
Control 6 EQ Q2 SysEx master channel (no feedback)
Control 7 EQ Gain 5 SysEx master channel (no feedback)
Control 8 EQ Frequency 5 SysEx master channel (no feedback)
Control 9 EQ Gain 3 SysEx master channel (no feedback)
Control 10 EQ Frequency 3 SysEx master channel (no feedback)
Control 11 EQ Q3 SysEx master channel (no feedback)
Control 12 EQ Gain 4 SysEx master channel (no feedback)
Control 13 EQ Frequency 4 SysEx master channel (no feedback)
Control 14 EQ Q4 SysEx master channel (no feedback)
Control 15 EQ Q5 SysEx master channel (no feedback)
Control 16 EQ Type SysEx master channel (no feedback)
Preset 51 XG Effects - Reverb Controller Channel Remark
Control 1 Reverb Type SysEx master channel (no feedback)
