✂ ✄ ☎ ✆ ✝ ✞ ✟ User's Guide
Preset 25 GS/XG Drum Pan NRPN master channel (no feedback)
Preset 26 GS/XG Drum Reverb NRPN master channel (no feedback)
Preset 27 GS/XG Drum Chorus NRPN master channel (no feedback)
Preset 28 GS/XG Drum Delay/Var NRPN master channel (no feedback)
Presets 23 ~ 28 control the drum kit, which would normally require the master channel to be set to
channel 10. The knobs all relate to the same drums on these presets as shown below, with each preset
controlling Pitch, Level, Pan, Reverb Send, Chorus Send or Delay/Var. Send depending on the preset
selected.
Preset 29 XG Drum Cutoff NRPN master channel (no feedback)
Preset 30 XG Drum Reson. NRPN master channel (no feedback)
Preset 31 XG Drum Attack NRPN master channel (no feedback)
Preset 32 XG Drum Decay NRPN master channel (no feedback)
Presets 29 ~ 32 control the drum kit, which would normally require the master channel to be set to
channel 10. The knobs all relate to the same drums on these presets as shown above, with each preset
controlling Filter Cut Off, Filter Resonance, Envelope Attack or Envelope Decay depending on the preset
selected.
The presets 29 ~ 32 use the same assignment of controls to drum instruments:
Control 1 Bass Drum Pitch Control 9 Bongo Pitch
Control 2 Snare Drum Pitch Control 10 Conga Pitch
Control 3 Tom Pitch Control 11 Timbale Pitch
Control 4 Hi-Hat Pitch Control 12 Hi Q Pitch
Control 5 Hand Clap Pitch Control 13 Seq Click Pitch
Control 6 Rim Shot Pitch Control 14 Finger Snap Pitch
Control 7 Crash Pitch Control 15 Click Noise Pitch
Control 8 Ride Pitch Control 16 Tambourine Pitch
Preset 33 XG Multi-Part Volume Level SysEx channels 1 - 16 (no feedback)
Preset 34 XG Multi-Part Pan SysEx channels 1 - 16 (no feedback)
Preset 35 XG Multi-Part Reverb Send SysEx channels 1 - 16 (no feedback)
Preset 36 XG Multi-Part Chorus Send SysEx channels 1 - 16 (no feedback)
Preset 37 XG Multi-Part Dry Level SysEx channels 1 - 16 (no feedback)
Preset 38 XG Multi-Part Variation Send SysEx channels 1 - 16 (no feedback)
Preset 39 XG Multi-Part Low EQ Gain SysEx channels 1 - 16 (no feedback)
Preset 40 XG Multi-Part Low EQ Frequ. SysEx channels 1 - 16 (no feedback)
Preset 41 XG Multi-Part High EQ Gain SysEx channels 1 - 16 (no feedback)
Preset 42 XG Multi-Part High EQ Frequ. SysEx channels 1 - 16 (no feedback)
Presets 33 ~ 42 are similar to the presets 1~4 and control the XG parts with SysEx messages (nearl all
Yamaha instruments). The 16 knobs controll the parameter of the 16 MIDI channels. Each preset
controls either Part volume, pan, reverb send, chorus send, dry level, variation effect send, low eq gain,
low eq frequency, high eq gain or high eq frequency.
