User's Guide
Preset 17 GS/XG general controls NRPN/controllers Channel Remark
Control 1 Filter Cutoff NRPN master channel (no feedback)
Control 2 Filter Resonance NRPN master channel (no feedback)
Control 3 Vibrato Rate NRPN master channel (no feedback)
Control 4 Vibrato Depth NRPN master channel (no feedback)
Control 5 Vibrato Delay NRPN master channel (no feedback)
Control 6 EG- Attack NRPN master channel (no feedback)
Control 7 EG Decay NRPN master channel (no feedback)
Control 8 EG Release NRPN master channel (no feedback)
Control 9 Pitch Bend PitchBend master channel (no feedback)
Control 10 Modulation Controller 1 master channel feedback
Control 11 Portam.Time Controller 5 master channel feedback
Control 12 Reverb Send Controller 9 master channel feedback
Control 13 Chorus Send Controller 93 master channel feedback
Control 14 Delay/Var Send Controller 94 master channel feedback
Control 15 Pan Controller 10 master channel feedback
Control 16 Volume Controller 7 master channel feedback
Preset 17 is an GS / XG general control preset [NRPN / controllers]. It has the top row of knobs
transmitting relevant NRPN controller data for GS/XG instruments, and the lower row is used for general
controllers.
Preset 18 AWE/SB 1 Masterchn NRPN/controllers Channel Remark
Control 1 Filter Cutoff Coarse NRPN master channel (no feedback)
Control 2 Filter Resonance Coarse NRPN master channel (no feedback)
Control 3 Vibrato Rate Coarse NRPN master channel (no feedback)
Control 4 Vibrato Depth Coarse NRPN master channel (no feedback)
Control 5 Vibrato Delay Coarse NRPN master channel (no feedback)
Control 6 EG- Attack Coarse NRPN master channel (no feedback)
Control 7 EG Decay Coarse NRPN master channel (no feedback)
Control 8 EG Release Coarse NRPN master channel (no feedback)
Control 9 Filter Cutoff Fine NRPN master channel (no feedback)
Control 10 Filter Resonance Fine NRPN master channel (no feedback)
Control 11 Vibrato Rate Fine NRPN master channel (no feedback)
Control 12 Vibrato Depth Fine NRPN master channel (no feedback)
Control 13 Vibrato Delay Fine NRPN master channel (no feedback)
Control 14 EG- Attack Fine NRPN master channel (no feedback)
Control 15 EG Decay Fine NRPN master channel (no feedback)
Control 16 EG Release Fine NRPN master channel (no feedback)
Preset 19 AWE/SB 2 NRPN/controllers Channel Remark
Control 1 LFO 1 Delay Coarse NRPN master channel (no feedback)
Control 2 LFO 1 Freq Coarse NRPN master channel (no feedback)
Control 3 Env1 Delay Coarse NRPN master channel (no feedback)
Control 4 Env1 Attack Coarse NRPN master channel (no feedback)
Control 5 Env1 Hold Coarse NRPN master channel (no feedback)
Control 6 Env1 Decay Coarse NRPN master channel (no feedback)
Control 7 Env1 Sustain Coarse NRPN master channel (no feedback)
Control 8 Env1 Release Coarse NRPN master channel (no feedback)
Control 9 LFO 1 Delay Fine NRPN master channel (no feedback)
Control 10 LFO 1 Freq Fine NRPN master channel (no feedback)
Control 11 Env1 Delay Fine NRPN master channel (no feedback)
Control 12 Env1 Attack Fine NRPN master channel (no feedback)
Control 13 Env1 Hold Fine NRPN master channel (no feedback)
Control 14 Env1 Decay Fine NRPN master channel (no feedback)
Control 15 Env1 Sustain Fine NRPN master channel (no feedback)
Control 16 Env1 Release Fine NRPN master channel (no feedback)
