A P P E N D I X
37
37
37
37
In the default settings of the Drehbank the external inputs 5, 6, 7, 8 corresponding
with the controller knobs 32, 48, 16, 64 are set for foot controller mode.
When a foot controller does not supply a control voltage covering the complete
control voltage range from 0...+5V the full MIDI data range is not available. In this
case the range of the corresponding control knob must be adjusted (same as for
CV mode).
If desired the operation modes of the 8 external inputs can be redefined (e.g. all 8
inputs redefined as foot controllers or CV inputs). This should only be done by a
authorised Service-dealer or directly by
Doepfer
Doepfer
Doepfer
Doepfer
, so as not to loose your
warranty. The same goes for the installation of the CV option, i.e. if the Drehbank
does not contain the CV option and this option has to be installed later.
If you then still want to modify the unit yourself in any way despite our warning we
will send you the Drehbank service manual for a small fee. The correct procedures
are listed in this manual. Simply send us DM 20 (or 10 Euro) with the serial
number of the Drehbank or a copy of your purchase receipt.
The Address is Doepfer Musikelektronik GmbH, Geigerstr.13, D-82166,
Graefelfing, Germany. The manual will also be available on our internet site
http://www.doepfer.com
.
