The Basics
What is the Drehbank?
The
Doepfer
Doepfer
Doepfer
Doepfer
Drehbank is a user definable Midi control unit with 64 rotary
control knobs.
Any midi event can be assigned to any control knob. Each knob lets you control
Midi events in the form of Midi-strings. You can control simple events like volume,
reverb, panorama, etc., or you can create complex SysEx strings.
The setting of each control knob is stored in a preset. A preset is organized into
two interchangable banks, each containing 64 control knob functions. The presets
are normally created in the Drehbank editor, stored on a PC, and from there sent
to the Drehbank
.
You can store a preset in the non-volatile memory (EEPROM) of the Drehbank. So
that the PC editor program can have a little snooze as soon as the preset is stored
in the memory of the Drehbank.
☺
Features
•
2 banks (each activated by a corresponding switch)
•
indicators for the activated bank (2 L.E.D.s one above each bank)
•
64 controllers per bank, each with the following parameters:
-
Midi strings with a maximum of 113 bytes per string.
-
Up to 16 definable variables per Midi string (each variable needs 7 Bytes).
-
Any variable can be assigned to any control knob.
-
For the variables there are 20 predefined data formats available.
-
The scale and range of each variable is adjustable.
-
control resolution can be definable up to 255 steps.
-
control threshold adjustable from1 to 255.
-
The offset and reference voltage of the AD converter is adjustable in 12 steps
per control knob.
•
The non-volatile saving of presets (2X64 control knobs).
•
„Plug
&
Pray“
☺ !You „switch on“ and the preset from the non-volatile memory
works.
•
The possibility to connect 8 external controllers.
•
‚Snapshot'
function.
