Doepfer Drehbank Midi Control Box (device no longer available) User Manual

Page 28

U S E R I N T E R F A C E

Edit Control: Type

Here you can select the data format of the variable. As default each Xn is defined
as "Normal byte" which is mostly used. The bit weight notation of a normal byte is
<76543210>. You have also the choice of other formats that you should only use if
you know what you are doing - if you do not, it is the best way to let it be "normal
byte".

Remark

The poperties dialogue supports only the normal byte
format.

Edit Control: Table

To show the values of property variables in plain text (e.g. Controller names
instead of numbers) and for easier editing each variable is associated with a table
that contains plain text for each value. The setting of the table takes no effect in the
control function and is also left unrecognized by the Drehbank. If you dont need a
special table then let it be on "Hex".

Attention

The settings of the tables are used only in the editor and has
no meaning in the DREHBANK device.

Edit Control: Range From

This setting represents the value of the assigned control knob at its left end
position (ccw, fully counter clock wise). For property variables this defines the
lowest available value.

Edit Control: Range To

This setting represents the value of the assigned control knob at its right end
position (cw, fully clock wise). For property variables this defines the highest
available value.

Note

You obtain an inverted control characteristic if "Range to" is
lower than "Range from".
