SOFT LIMIT
The user can set up the soft limit to define the left and right
boundaries for the pan movement
SOFT LIMIT:Move the cursor here and press IRIS OPEN to
enter.Now the joystick to select “ON” or“OFF”to ennable or
disable this function.
LEFT LIMIT:Move the cursor here and there IRIS OPEN to
enter .Now the user can move the joystick to control the PAN
movement of the dome to a defined positon for the left
limit .Press IRIS OPEN to confirm.
RIGHT LIMIT:Move the cursor here and press IRIS OPEN to
enter.Now the user can move the joystick to control the PAN
movement of the dome to a defined position for the right
limit .Press IRIS OPEN to confirm.
LIMIT DELETE:Move the cursor here and press IRIS OPEN to
delete all the settings.
ADVANCED
TEST>
MAIN MENU
LANGUAGE:ENGLIS
RESTART
FACTORY DEFAULTS
HEIP
EXIT
DOME SETTINGS
K>
BACK EXIT
LIMIT SETTING
SOFT LIMIT OFF
LIMIT DELETE
BACK EXIT
