24
LANGUAGE
The language for the on‐screen menus is Selectable.
To change the display language:
Press Iris Open to enter selection.
All on‐screen menus are changed to the
selected language.
SYSTEM INFORMATION
The user can check the dome system information as required. The system
information includes: Dome ID, dome address, baud rate, protocol,
temperature, voltage, alarm info, dome title, version, date, time, and
temperature scale.
Use the following steps to display the
System Information screens:
1. Use the joystick to position the cursor along the SYSTEM
INFORMATION.
2. Press Iris Open. The SYSTEM INFORMATION screen opens.
3. Mover the joystick up and town to select the item.
4. Press Iris Open to enter the setup of each item. SYETEM INFORMATION
DOME ID ;1234567890
ADDRESS:001
BAUDRATE:2400
PROTOCOL:PELCO-D
TEMPERATURE:31
VOLTAGE:12.0V
ALARM:000000 00
BACK EXIT
OTHERS
VERSION:V220ST
TILTE:SDI DOME
DARE:2009-01-01
TIME:10:20:00
TEMP SCALE:CELSIUS
BACK EXIT
