1) Protocol Setup
Our IR speed dome supports three protocols including Pelco P, Pelco D and HS.
All of them supports baud rate of 9600bps、4800bps、2400bps.
Set the No.1~4 dip switch for the protocol configuration.
Protocol SW2‐1 SW2‐2 SW2‐3 SW2‐4
HS OFF OFF OFF OFF
PELCO P ON OFF OFF OFF
PELCO D OFF ON OFF OFF
Reserved … … … …
2) Baud Rate Setup
Set the No.5~6 dip switch for the baud rate configuration.
Baud Rate SW2‐5 SW2‐6
9600 OFF OFF
4800 ON OFF
2400 OFF ON
Reserved … …
