CY7C1018DV33
Document #: 38-05465 Rev. *D Page 6 of 9
Write Cycle No. 1 (CE Controlled) [16, 17]
Write Cycle No. 2 (WE Controlled, OE HIGH During Write)
[16, 17]
Switching Waveforms (continued)
t
WC
DATA VALID
t
AW
t
SA
t
PWE
t
HA
t
HD
t
SD
t
SCE
t
SCE
CE
WE
DATA I/O
ADDRESS
t
HD
t
SD
t
PWE
t
SA
t
HA
t
AW
t
SCE
t
WC
t
HZOE
DATA
IN
VALID
NOTE 18
CE
ADDRESS
WE
DATA I/O
OE
Notes
16. Data I/O is high impedance if OE = V
IH
.
17. If CE goes HIGH simultaneously with WE going HIGH, the output remains in a high-impedance state.
18. During this period the I/Os are in the output state and input signals should not be applied.
