4
• Starts/Stops scanning for Max/Min/Peak values. (Standard Memory)
• Starts/Stops automatic recording of values into memory (Continuous Data Logging Model).
• Loads displayed value into memory (On-Demand Data Logging Model).
• Enters Recall Mode to review statistics and recorded Data.
• In recall mode, changes display from LAST
➔ MAX ➔ MIN ➔ PEAK ➔ LAST ➔ MAX etc.
• When in Data Logging Mode: changes display from LAST ➔ MAX ➔ MIN ➔ PEAK.
➔ AVERAGE ➔ STANDARD DEVIATION➔ DATA #1➔ DATA #2 ➔ DATA #3 etc.
• Turns power on.
• Turns power off if pressed and held for 5 or more seconds.
• Exits from Recall Mode when reviewing data.
• Clears all data in Basic Memory (“CCCC” momentarily shown on display).
• Zeros gauge (“Tare”) for use in any orientation (“Gravity Correction”).
Key Description of Functions
3.00 DESCRIPTION OF MEMBRANE KEY FUNCTIONS
STORE
RECALL
POWER
EXIT
RECALL STORE +
POWER
EXIT
RECALL +
* When the units of measure are changed to grams, the “gf” indicator will
momentarily flash on and then turn off. Otherwise the “lb.” or “oz” indicators
will be shown.
• Changes units of measure from grams (or Kg) to pounds (or ounces) and back again
each time this key combination is pressed. STORE
POWER
EXIT
+
*
21
8.34 Special Calibration
If the standard Factory Calibration and
the Field Calibration Adjustment does not
provide the desired accuracy, a Special
Calibration can be ordered. A l0' sample
of the process material must be provided
for calibration purposes.
8.40 On-Line Mounting Holes
The DTMB is supplied with two threaded
holes for on-line mounting in a fixed posi-
tion when performing measurements over
an extended period.
Thread Size M5 (metric)
Thread Depth 7.5 mm (max.)
W
Mounting
holes
SP
