Appendix D - Spindle and Model Codes
Each spindle has a two digit code which is scrolled to via the keypad on the DV-I+. The spindle code
directs the DV-I+ to calculate viscosity for the spindle that is being used. The spindle multiplyer
constant (SMC) is used to calculate full scale viscosity range for any spindle/speed combination (refer
to Appendix E). Spindle codes are listed in Table D-1.
SPINDLE
CODE
SMC
RV1
01
1
RV2
02
4
RV3
03
10
RV4
04
20
RV5
05
40
RV6
06
100
RV7
07
400
HA1
01
1
HA2
02
4
HA3
03
10
HA4
04
20
HA5
05
40
HA6
06
100
HA7
07
400
HB1
01
1
HB2
02
4
HB3
03
10
HB4
04
20
HB5
05
40
HB6
06
100
HB7
07
400
LV1
61
6.4
LV2
62
32
LV3
63
128
LV4
64
640
LV5
65
1280
SPIRAL
70
105
T-A
91
20
T-B
92
40
T-C
93
100
T-D
94
200
T-E
95
500
T-F
96
1000
SPINDLE
CODE
SMC
ULA 00
0.64
DIN-ULA 85
1.22
TSEL-DIN-81
81
3.7
SSA-DIN-82
82
3.75
SSA-DIN-83
83
12.09
ULA-DIN-85
85
1.22
ULA-DIN-86
86
3.65
ULA-DIN-87
87
12.13
SC4-14
14
125
SC4-15
15
50
SC4-16
16
128
SC4-18
18
3.2
SC4-21
21
5
SC4-25
25
512
SC4-27/27D
27
25
SC4-28
28
50
SC4-29
29
100
SC4-31
31
32
SC4-34
34
64
SC4-37
37
25
CPE40
40
0.327
CPE41
41
1.228
CPE42
42
0.64
CPE51
51
5.178
CPE52
52
9.922
V-71
71
2.62
V-72
72
11.10
V-73
73
53.50
Table D-1
Note: Spindle codes 66, 67 and 74 are not in the firmware for the DV-I+ Spindle Table D-1. Manual
calculations are required to convert torque readings to shear stress and viscosity values.
