PeciFicAtioNs

Virtual Data Cables (VDC)

GPIO

4x in; 4x out

Isolated or TTL

Inputs: 4 terminal blocks, individually

configurable as Isolated or TTL
Outputs: 4 terminal blocks
Maximum inputs to network VDC slots: 14

MIDI

In, Out

5‑pin DIN

Maximum inputs to network VDC slots: 14

RS-232 DB9 connector

DIP switch configured

RS-232

Baud

Rates:

1200, 2400, 4800, 7200, 9600, 14400,

19200, 28800, 38400, 57600,

31250 (preset for MIDI)
Maximum inputs to network VDC slots: 7

Power Supply

100‑240VAC

50‑60Hz, 24W

Internal switching power supply;

IEC connector, interchangeable

Maximum Ambient

Temperature

50°C

Fuse

F4AL

Dimensions

2U; 19”w x 8”d x 3.5”h;

482.6 x 203 x 88 mm

Weight

9 pounds;

4.1 kg

All Aviom products are designed and manufactured in the USA.
