Vostok Deluxe
Analogue Solutions | Circuits – Main PANEL
47
STEP controls
It is an 8 step sequencer, so there are 8 controls! Voltage range is approximately 0-5V.
STEP LEDs
These light up in turn to show the active step.
# OF REPEATS control
This determines how many times each step is played before the sequencer advances to the next step. Each step can be repeated from
between one to eight times.
This gives the effect of the sequencer being up to 64 steps long! Using a repeat setting of three gives a ¾ time feel.
STEP ONE socket
This socket will output a 5V Gate when ever the sequencer is on step one.
RESET socket
Send a 5V gate to this input socket to reset the sequencer to step one.
CLOCK socket
