Vostok Deluxe
24 Circuits – Main PANEL | Analogue Solutions
VCF1 OUT socket
This is the audio output from VCF1 filter.
VCF1 MODE toggle switch
When up, VCF1 performs as a highpass filter (HP). When down, performs as a lowpass filter (LP).
CUT-OFF control
This sets the filter cut-off frequency. It is used to change the tonal characteristics of the audio going through the filter.
RESO’ control
The Resonance control increases feedback at the filter cut-off frequency. What some people like the technically refer to as squigyness.
LEVEL control / CV socket
This is the filter cut-off modulation CV input. The LEVEL control is the signal level/modulation strength conrol.
