Vostok Deluxe
42 Circuits – Main PANEL | Analogue Solutions
LEVEL control
This is level control for the signal input (above).
OUT socket
This is the CV output from the sample and hold circuit. Maybe try patching this to filter cut-off or VCO pitch.
LEVEL control
This is the S+H signal output level control.
CLOCK socket
This is the S+H clock input socket.
Each time the input signal goes high the input signal will be sampled and held, until the next clock.
Typically use the square wave output from an LFO, or, the Gate signal from the MIDI converter.
A typical use of S+H is to create a stepped random voltage. To do this patch Noise to the IN, LFO square wave to the CLOCK.
SLEW control
Slew is like portamento. Use this control to smooth out sudden changed in voltage change at the S+H output.
