Vostok Deluxe
Analogue Solutions | Circuits – Main PANEL 21
This is a pitch CVh control input socket. The is pre-glide. Normally the output of a CV keyboard, or the MIDI-CV converter PITCH CV output
would be patched here.
CV2 socket
This is a modulation CV control input socket. The is post-glide. Normally the output of a LFO or would be patched here.
PW socket (VCOs 1 & 3 only)
This is a modulation CV input socket to control pulse width with an external voltage such as LFO or EG.
SUB socket (VCO2 only)
This is the sub-osc audio output. Sub-Osc is an audio output from the VCO that is one octave lower than the other Saw/Square outputs. Mix
with the other waveforms for a deeper, fuller sound. Great for bass!
SAW socket
This is the Sawtooth waveform audio output
SQR socket
This is the Square waveform/PW waveform audio output.
