Specifications
CRT Size 17“ CRT (16.0V40.6 cm Viewable Image Size) Flat Square
Dot-pitch 0.27 mm (H: 0.236 mm x V: 0.137 mm)
Phosphor/Glass RGB short persistence (Hi-EV RED) Crystal pigment/Dark Tint
Surface treatment Advanced AGRAS (Anti-Glare, anti-Reflective and Anti-Static) Coat
Input signals Video signaling RGB analog
Signal level 0.7 Vp-p (without sync, signal), 1.0 Vp-p (with sync, signal)
Sync signal HA/ separate (TTL level), H/V composite (TTL level),
Sync - on - Green is not available.
Horizontal Frequency Range Allowable Frequency Range: 30.0 kHz to 70.0 kHz
Vertical Frequency Range Allowable Frequency Range: 50.0 Hz to 160.0 Hz
Preset mode 1 preset and 7 reservation (See page 15)
Video Maximum Pixel Clock 108 MHz (typ.)
Resolution 1280 dots(H) X 1024 lines (V) at 60 Hz‘
Viewable Image Size Factory preset
(H X V, Diagonal) Full scan (Typical)
11.81" X 8.86", 14.8" Diagonal “
12.80" X 9.60", 16.0" Diagonal “
Display Color Analog input, unlimited number of colors “*
Connectors Video Signal 15-pin mini D-Sub connector (female pins)
Power supply CEE 22 type 3-pin connector
Input power AC 100-120 V (50/60 Hz)
Power consumption 95W typ. / < 15W stand-by, < 8W sleep mode (See page 13)
Controls Front Power ON/OFF, |T|, a, B, ¡2} keys
On-Screen Display Contrast, Brightness, Size & Pos (H. Position, H. Size, V. Position,
V. Size), Geometry (V. Pincushion, Side Pincushion Balance,
Trapezoid, Parallelogram), Rotation (Tilt), Color Temp. (9300K +
8 MPCD, 7500 K, 6500K, 5000K, User Ctolor adjustment). Recall,
Video Level select (0.7V/1.0V), Language select (French, English,
Spanish), OSD Position, Degauss, Signal, Monitor Self Test
Tilt/swivel 13“ up, 4“ down, 90“ each to right and left
Dimensions ,(W x H x D) (15.9“ X 15.9" X 16.7")
405 mm X 404.5 mm x 425 mm
Weight (monitor only) 15.8 kg (34.7 lbs)
Approvals UL1950, CSA
22.2
No.950, DHHS,
FCC Class B, MPRII, NUTEK.
VESA DPMS /
E nergy S tar «
Standard , 1 detachable signal cable for VGA,SVGA.
1 detachable AC power supply cord.
Operating Instructions, Warranty card
Environmental conditions
Operating Temperature
Humidity
Altitude
0 to 35*C (32 to 95*F)
5 to 90% (no condensation)
10,000 ft
Storage Temperature
Humidity
Altitude
-20 to + 60*C (-4 to 140“F)
5 to 90% (no condensation)
40,000 ft
Windows*95 Plug & Play VESA DDC1/2B meets Windows*95 Plug & Play Requirements
Note:
*The on-screen image may flicker if the display Is operated with the Vertical freq. under 60 Hz .
‘‘Depends on signal timing used, see page 14 .
‘“Number of colors depends on the Video Board used, memory installed, and RAMDAC
{Random Access Memory Digital to Analog Converter),
Specifications and design are subject to change without notice.
This product may be subject to export regulations.
