< On-Screen Display>
< Function and Operation>
Size & Pos.
Press the [D key to select the HorizonU
Vertical Size adjustments.
i\
Position / Horizontal Size / Vertical Position /
Ш=| Horizontal Position
adjustment
H . P o s i t i o n
50
[Qi Э Q Ш
The horizontal position of the image can be
adjusted. Press the Э key to move it to the left,
the В key to move it to the right.
* Press the
Ш
key to save the adjustment.
Horizontal Size
adjustment
H . S i z e
[dS Э CH
The horizontal size of the image can be adjusted.
Press the H key to make the image smaller, the
B key to make it larger. Then press the
H]
key to
save the adjustment.
* Setting the image in the center of the screen will
make the size adjustment easier.
Q Vertical Position
adjustment
V . P o s i t i o n
50
[d S 1^ Ш - Ш
The vertical position of the image can be
adjusted. Press the a key to move it downward,
the B key to move it upward.
* Press the Ul key to save the adjustment.
m Vertical Size adjustment
Cd H S Ш : tl]
The vertical size of the image can be adjusted.
Press the 3 key to make the image smaller, the
B key to make it larger. Then press the D] key to
save the adjustment.
* Setting the image in the center of the screen
will make the size adjustment easier.
FU
Geometry
Press the [H key to select the Vertical Pincushion / Side Pincushion Balance / Trapezoid
/ Parallelogram adjustments.
ГТ Vertical Pincushion adjustment
V. P i n c u s h i o n
50
Oa Q/7 -[1
The image can be corrected for Pin / Barrel
distortion. Press the a key to decrease the
Pin / Barrel distortion of the image, the B key
to increase it.
- 1 0 -
