Recommended timing
640 x 400 @ 85 Hz 640x480© 85 Hz 720 x 400 @ 85 Hz
Dot clock 31.5000 MHz 36.0000 MHz 35.5000 MHz
fH 37.860 kHz 43.269 kHz 37.928 kHz
_ A H-Period 26.413 us ( 832dots) 23.111 us ( 832dots) 26.366 us ( 936dots)
C
F H-Blanking 6.095 us{ 192dots) 5.333 us( 192dots) 6.085 us( 216dots)
o
N
B H-Sync width 2.032 us ( 64dots) 1.556 us ( 56dots) 2.028 us( 72dots)
o
C H-Back porch 3.048 us ( 96dots) 2.222 us ( SOdots) 3.042 us ( 108dots)
X D H-Active 20.317 us ( 640dots) 17.778 us( 640dots) 20.282 us ( 720dots)
E H-Front porch 1.016 us( 32dots) 1.556 us { 56dots) 1.014 us( 36dots)
fV 85.080 Hz 85.010 Hz 85.040 Hz
P V-Period 11.754 ms (445lines) 11.763 ms (509lines) 11.759 ms(446lines)
"5
o
U V-Blanking 1.189 ms ( 45lines) 0.670 ms ( 291ines) 1.213 ms ( 46lines)
Q V-Sync width 0.079 ms ( 3lines) 0.069 ms i 3lines) 0.079 ms ( 3lines)
Q
>
R V-Back porch 1.083 ms( 41 lines) 0.578 ms ( 251ines) 1.107 ms ( 42lines)
S V-Active 10.565 ms (400lines)11.093 ms (480lines)10.546 ms( 400lines)
T V-Front porch 0.026 ms( nine) 0.023 ms ( 1line) 0.026 ms( nine)
Sync polarity (HA/) Negative/Positive Negative/Negative Negative/Positive
Recommended timing
800 x 600 @ 85 Hz 1024 x 768 @85 Hz 1152 x 900 © 66 Hz
Dot clock 56.2500 MHz 94.5000 MHz 92.9407 MHz
fH 53.674 kHz 68.677 kHz 61.797 kHz
—
A H-Period 18.631 us(1048dots) 14.561 us(1376dots) 16.182 us(1504dots)
C
F H-Blanking 4.409 us{ 248dots) 3.725 us ( 352dots) 3.787 us( 352dots)
o
N
B H-Sync width 1.138 us { 64dots) 1.016 us( 96dots) 1.377 us ( 128dots)
o
C H-Back porch 2.702 us ( 152dots) 2.201 us( 208dots) 2.098 us ( 195dots)
X D H-Active 14.222 us ( 800dots) 10.836 us(1024dots) 12.395 us(1152dots)
E H-Front porch 0.569 us { 32dots) 0.508 us ( 48dots) 0.312 us( 29dots)
fV 85.060 Hz 85.000 Hz 65.950 Hz
P V-Period 11.756 ms (631 lines) 11.765 ms(808!ines) 15.163 ms ( 937lines)
la
u
U V-Blanking 0.578 ms ( 31 lines) 0.582 ms ( 401ines) 0.599 ms( 37lines)
Q V-Sync width 0.056 ms( 3lines) 0.044 ms ( 3lines) 0.065 ms( 4lines)
0
>
R V-Back porch 0.503 ms ( 27lines) 0.524 ms ( 36lines) 0.502 ms( 31lines)
S V-Active 11.179 ms (600lines) 11.183 ms(768lines) 14.564 ms ( 9001ines)
T V-Front porch 0.019 ms( nine) 0.015 ms( nine) 0.032 ms ( 21ines)
Sync polarity (H/V) Positive/Positive Positive/Positive Composite
