< On-Screen Display> < Function and Operation>
Q Side Pincushion Balance
S i d e P i n . B a l .
5 0
UCLC^O -m
The image can be corrected for barrel balance
distortion. Press the 3 key to expand to the left of
the image, the B key to expand to the right it.
r\
Trapezoid adjustment
T ra p e z o i d
50
m d c i o - m
The image can be corrected for trapezoidal
distortion.
Press the 3 key to make the top edge narrower,
the B key to make the bottom edge narrower.
[J Parallelogram adjustment
P a r a l l e l o g r a m
5 0
Oa QZ7 :
The image can be corrected for parallelogram
distortion.
Press the 3 key to collapse the parallelogram to
the left, the B key to collapse it to the right.
Ol Rotation (Image tilt)
adjustment
R o t a t i o n
50
Use this to adjust for tilt on the screen.
Press the 3 key to rotate the image slightly
counterclockwise, the B key to rotate the image
slightly clockwise.
*Pressing the 3 and B keys simultaneously
adjusts rotation to its factory preset level.
1*^ Color Temp
C o l o r T e m p
□ 2 3 4 5
9300K+8
The white in the image can be adjusted.
1) Use the 3 or B keys to select 1: 9300 K + 8
MPCD, 2: 7500 K, 3: 6500 K, 4: 5000 K or 5: the
user’s preferred color.
2) If “ 5: user’s color" is selected, “ H] ” appears
in the lower right of the On-Screen Display.
Press the front { 2 } key to select, the User Color
adjustment screen.
User Color adjustment
R100
G 80
I I
B 60
Note: Record the initial values of R, G and B
here before making any adjustments:
R { Red) _____________
G { Green ) _____________
B ( Blue )
_____________
The white in the video image can be adjusted to
the user’s preferred color.
1) Use the [U key to select R (red) or G (green)
or B (blue).
2) Use the 3 or B keys to adjust the color as
desired.
* Recall of the user’s color is not possible, so
make a note of the initial setting before
adjusting.
